MY OTHER NOTABLE WORKS

1. SOLIDWORKS DESIGNS AND PROJECTS

1.1. BOTTLE CAP-NIPPLE PRESSING

This project is mainly used for toilet cleaner bottle cap compilation with nipple. This design can be used for similar products with no or little modification.

1.2. TRAY CLEANER

A machine that is capable of clean cake trays by brushing it after the cake is disposed from the tray.

1.3. IN MOLD LABELLING

This machine was designed to label cups, bottles with molding.

1.4. PALLETIZING SYSTEM

This is a fully automated palletizing system with a conveyor, sensor, and pneumatic cylinders.

1.5. AUTOMATIC COLOR FILLING AND CAN SEALING MACHINE

This machine is able to fill containers with color and seal the can both automatically using suction cup, rotary pneumatic cylinder and proximity sensor.

1.6. A GARMENTS PAPER/TISSUE CUTTING MACHINE

This machine was designed to be able to automatically cut paper/tissue for garments industry in a predetermined shape and size.

2. AUTOCAD ELECTRICAL CIRCUIT DESIGNS

I have designed over-all control panel circuit including PLC, relay, terminal block, ACB, MC, VFD, RIO and parts of field devices like pressure transmitter, TK4S etc.

3. CATIA DESIGNS

I have worked with CATIA for several projects. I have worked on Catia V5 designs migrating to Catia V6 (DBDI process).

4. SCADA DESIGNS

SCADA software is used for monitoring and control of field devices in industry, which allows modification by designers and programmers. I have designed SCADA pages. One sample SCADA page designed by me is demonstrated below.

5. PYROSIM PROJECTS

I have analyzed fire and smoke flow and propagation in PyroSim software.
